• 8K/UltraHD2/4K/UltraHD/2K/HD/SD up to 50/60p
• 4x bidirectional 12G-SDI connections with 16-channel embedded audio
• HDMI 2.0 output, 4K/UltraHD HFR, plus 8K to 4K downsampling
• RGB 4:4:4 12-bit (4K/UltraHD) workflows supported
• YCbCr 4:2:2 10-bit and HFR workflows supported
• Up to 12-bit LUT support (.cube)
• 8K support for Apple Final Cut Pro, Adobe Premiere Pro and Avid Media Composer and much more
• Multi-Channel support with OBS Studio, vMix and Telestream Wirecast
• 8K or multi-channel 4K support for OEM applications with AJA SDK
• Dynamic FPGA Firmware Reconfiguration for quick mode changes
• 4K Closed Caption Support
• VPID signaling for SDR/HDR Transfer Characteristics, Colorimetry and Luminance via SDI
• PQ, HLG, HDR10 and Dolby Vision Support
• HDR Metadata Capture and Auto Playback Detection
• Includes support for the latest Apple silicon
• Reference Input on card (Analog black burst or Tri-level)
• Included breakout cable for LTC, RS-422, 8-ch AES/EBU
• Three year warranty

AJA Desktop Software is optimized for the latest Apple silicon with native support for AJA macOS drivers, application plug-ins, AJA Control Room, AJA Control Panel, and AJA System Test.

KONA 5 boasts 4x bidirectional 12G-SDI spigots and a Reference Input directly on the card bracket. The 4x HDBNC SDI connections can be used in a wide variety of configurations to support your creative needs; use four cables simultaneously to support either 8K/UltraHD2 (via 4x 12G-SDI) or 4K/UltraHD (via 3G-SDI), alternatively use a single cable for input and a single cable for simultaneous pass-through/output for either 4K/UltraHD (via 1x 12G-, or 6G-SDI) or HD/2K (via 1x 3G-SDI, or even single/dual link 1.5G-SDI).

A full-sized HDMI 2.0 connection offers monitoring and output, with HDR, Deep Color and HFR support. Across the board, KONA 5 is the professional’s choice for post, broadcast, graphics, virtual sets, pre-viz, live compositing and more.

KONA 5 ships with an included breakout cable that offers extensive connectivity for AES, RS-422 control support and Reference:

• 8-Channels of AES/EBU (BNC) In

• 8-Channels of AES/EBU (BNC) Out

• RS-422 9-pin connector for control

• LTC In and Out

KONA 5 also ships with 5x HDBNC to full-size BNC cables to ensure out-of-the box compatibility with your SDI infrastructure.

HDR (High Dynamic Range) provides the ability to display a wider and richer range of colors, much brighter whites, and much deeper, darker blacks than standard signals allow. This gives your imagery a more ‘dynamic’ look and allows for natural true to life colors to be communicated to your audience.

KONA 5 HDR workflows can also benefit from AJA’s Control Room application and its companion, AJA Control Panel, which comes complete with built-in HDR test patterns.

AJA Control Room provides VPID signaling for SDR/HDR Transfer Characteristics, Colorimetry and Luminance transfer characteristics over SDI, bringing flexible output options to your KONA 5. HDMI ports that were already HDR compatible will work simultaneously, for HDR output via both SDI and HDMI.

AJA Control Room software adds support for HDR metadata capture from an incoming SDI or HDMI signal. The captured .mov video file will have embedded HDR metadata, allowing the file to be played back at its intended dynamic range.

AJA Control Room software also provides the KONA 5 with HDR Auto Playback Detection. Embedded HDR metadata in a recorded .mov file, is read and used to automatically set the HDR format on the monitor(s) connected to the KONA 5 HDMI and/or SDI outputs. Support for file-based .mov HDR outputs with metadata from Adobe Premiere Pro/Adobe Media Encoder HDR files is also available. Screening those rendered outputs is a simple and hi-quality experience with AJA Control Room. Every frame is presented in its full-quality, at the timing intended, and with the proper HDR format set correctly and automatically.

Explore more of our HDR Solutions here:

HDR Solutions

At a time when 8K recording devices are prohibitively expensive, unlock the next generation power of 8K capture and playback via KONA 5 and use a more cost effective workstation. Capture 8K on Windows, Linux or macOS for example, and use the file immediately in your NLE or other application of choice.

The latest AJA Desktop Software advances 8K workflows with KONA 5 by providing native support for 8K video in Adobe Premiere Pro, Apple Final Cut Pro and Avid Media Composer plus many other applications. KONA 5 offers the broadest video format of any AJA product, providing and easy transition to larger format video workflows for Sports, eSports, Virtual Production, and other cutting-edge workflows.

For those who hop between 8K visual effects sequences and 4K live action footage, KONA 5 now also supports fast-bitfile-switching. In under 10 seconds you can flip between a KONA 5 personality tuned for 8K operations, to one dedicated to 4K and below. No waiting for firmware to update, no reboots required. Just powerful options to make your day go that bit faster and easier.

KONA 5 now supports fast bitfile-switching. In under 10 seconds you can flip between a KONA 5 personality tuned for 8K operations, to one dedicated to 4K and below. No waiting for firmware to update, no reboots required.

AJA Control Room

• Supports CEA-608 or 608-in-708 via ANC extraction firmware.

Avid & Adobe Plugins

• All SMPTE-291 (ANC) based captions supported.
• Adobe Premiere Pro supports native 708 if the raw data is available. For instance in the Adobe plug-ins we handle the case where Premiere hands us full 708 data, we just pass it through to the device.
• Avid Media Composer supports active video ANC (line 21) or ANC via ANC extractor/inserter (up to UHD/4K).

Connect your digital sources via 12G-SDI to KONA 5 for capture to and playback from a wide variety of formats. Master to destinations using high quality professional SDI outputs, machine control and analog or tri-level reference.
Monitor via HDMI 2.0 output for 4K or HD, or utilize as a 4K down sample from 8K SDI, so you can make use of your existing 4K monitors for 8K work.

KONA 5 also supports VPID signaling for SDR/HDR Transfer Characteristics, Colorimetry and Luminance via SDI.

• PQ, HLG, HDR10 and Dolby Vision* Support
• HDR Metadata Capture and Auto Playback Detection

*Dolby Vision and HDR10 integration available when using the AJA SDK, or using compatible 3rd party software.

Download Workflow

Supports macOS, Windows, and Linux Ubuntu / Rocky. Please see Release Notes for details and version information which can be found in the Downloads, Software tab.

AJA Desktop products offer unparalleled workflow compatibility with a range of software applications that span production, post, and delivery, and more. Please click here for compatibility information.

AJA’s technical support is recognized as among the best in the industry and is available to all AJA customers. If you need assistance with any aspect of your KONA installation, configuration, operation or encounter any technical issue, AJA Support will work with you to get up and running.

KONA products are covered by a generous three year warranty. Please see the individual Product’s Manual for additional specifics around warranty conditions for the product itself.
